WORKING PRINCIPLE
The rotating sprinkler system water evenly dispersed in the film. And then from the top of axial flow fan will be dry air at the bottom of the belt, so that contact with hot water and air convection arising from evaporation, so that the water temperature down, at the end of the cooling water from the basin and collected by the heat pump operation to be recycled.
SPECIFICATIONS
DIA/PROJECT
POWER
CONSUMPTION
HEAD
CAPACITY(m3)
COLD CAPACITY
M
L/min
m3/h
LOW
HIGHT
11/4〃
1/2HP
220/380V 50HZ
12/13/14
85/50/40
5/3/2.5
5
10
11/2〃
1HP
220/380V 50HZ
15/16/17
135/100/61
8/6/3.5
15
20
2〃
2HP
220/380V 50HZ
17/18/19
225/200/165
13.5/12/10
25
30
21/2〃
3HP
220/380V 50HZ
17/18/19
420/350/280
25/21/17
40
50
3〃
5HP
220/380V 50HZ
19/20/21
650/600/560
43/36/33.5
60
80
4〃
7.5HP
380/660V 50HZ
19/20/21
920/800/760
55/48/45.5
80
100
4〃
10HP
380/660V 50HZ
19/20/21
1250/1100/900
75/66/54
100
125
5〃
15HP
380/660V 50HZ
19/20/21
3200/2800/2650
192/168/159
125
150
5〃
20HP
380/660V 50HZ
19/20/21
4600/4000/3500
276/240/210
150
180
